Stonex R1 – 102 (Topcon)

August 28, 2014
by surveyinstrument
0 Comment

Stonex-R1

Reflectorless Total Station
The R1 provides superior performance at an unbeatable price for survey and construction applications. It’s built tough to survive in extreme conditions, yet easy to set up and put to work quickly. R1 features 200m reflector less operation and up to 2000m using a single prism. There’s even a built in laser pointer to aid in layout work. With a 24-key alphanumeric interface, 24,000 point capable memory, and up to three days of operation off of a single charge, R1 is the perfect solution for medium duty survey and construction layout.

  • Description
  • Specification
  • Gallery
  • Download
  • Submit Enquiry
  • Reflectorless Total Station
    The R1 provides superior performance at an unbeatable price for survey and construction applications. It’s built tough to survive in extreme conditions, yet easy to set up and put to work quickly. R1 features 200m reflector less operation and up to 2000m using a single prism. There’s even a built in laser pointer to aid in layout work. With a 24-key alphanumeric interface, 24,000 point capable memory, and up to three days of operation off of a single charge, R1 is the perfect solution for medium duty survey and construction layout.

    Features

    • Angle Accurncy:2″
    • Angle Resolution:1″/5″
    • EDM Renge: 3000m Single Prism 200m Reflectorless
    • Meeasurement Time:1.1 sec.
    • Waterproof Rating:IP54
    • Battery Life (20’c) Approx. 23 hours
      •  Technical Specification

        Telescope
        Magnification 30x
        Image Erect
        Field of View 1°30′
        Resolving power 3.0″
        Minimum focus distance 1.3m
        Angle measurement
        Display resolution 1″/ 5″
        Accuracy 2″
        Axis compensator 1 axis, ±3′ (Compensation range)
        Distance measurement
        Measuring range – Reflectorless 200m
        Measuring range – Prism 2,000m (Single Prism)
        Accuracy – Reflectorless (3+2 ppm x D)mm
        Accuracy – Prism (2+2 ppm x D)mm
        Measuring time (Fine) – Reflectorless 1.1s
        Measuring time (Fine) – Prism 1.1s
        Interface and Data Management
        Display Graphic LCD
        Keyboard 24 Alpha-Numeric Keys
        Control panel location 2 sides
        Data storage – Internal memory 24,000 pts
        Data storage – Plug-in memory device N/A
        Interface Serial RS-232C
        General
        Levels – Plate Level 30″ / 2mm
        Levels – Circular level 10′ / 2mm
        Optical plummet (Magnification) 3x
        Dust and water protection IP54
        Operating temperature -20 to 50ºC
        Size with handle 336(H) x 184(W) x 172(L) mm
        Weight with battery & tribrach 4.9kg
        Power supply
        Battery BT-77Q
        Operating time(20ºC) Approx. 23 hours
