Packing list 1 Electronic Theodolite x 1 2 Rechargable battery x 1 3 Dry Battery Case x 1 4 Charger x 1 5 Mini cool bag x 1 6 User Guide x 1 7 Laser Target (provided with laser theodolite) 8 Bend Eyepiece (optional) 9 Instrument Suitcase x 1
-
Technical Specification
DE-2B/DEL-2B Telescope Image Erect Magnification 30X Object lans aperture 45mm Resolving power 3” Field of view 1⁰30′ Min.focus 1.35m Stadia ratio 100 Constant 0 Length 155mm Angle
MeasurementCode type Absolute code Min. reading 1”/5” Accuracy(1) 2”/5”/10” Circle diametar 79mm Measuring unit 360⁰/400gon/6400mll TILT Compensator
range±3′ Display LED Double side Optical
PlummetMagnification 3x Field of view 6⁰ Focus range 0.5m-∞ Laser
plummet&
pointerWave langth 630-670mm Power 6mW Laser range 180m Laser spot diameter 52mm Bubble Plate level 30’/2mm Circuler bubble 6’/2mm Power Rechargable
batteryNi-MH 8V
1200mAH
